EV-04 Machine Performance Parameters | ||||
Machine parameters (theoretical parameters) | Machine parameters | |||
project | parameter | project | parameter | |
(KG)Rated load | 400 | (MM)Total length | 3280 | |
(m³)Rated capacity of bucket | 0.22 | (MM)Bucket height (total width) | 1040 | |
(mm)Tipping height | 1360 | (MM)Total height | 2100 | |
(MM)Lifting Height | 2200 | (MM)wheelbasewheelbase | 1350 | |
(MM)Unloading distance | 600 | (MM)Track width | 860 | |
(KG)Maximum load capacity | 400/600 | (MM)Minimum ground clearance | 200 | |
(KG)Maximum Rising Power | 550 | (KG)Net weight | 1150 | |
(°)Max Climb Capability | 15 | Number of battery packs | 5 | |
(°)Maximum steering angle | 35±1 | (V)Rated voltage | 60 | |
drive system | steering system | |||
project | parameter | project | parameter | |
Hydraulic system | Types of steering hydraulic systems | Fully hydraulic steering | ||
Motor model | YS155-3-60-S02A | (mpa)system pressure | 16 | |
(V)Voltage | 60 | Types of steering pumps | Gear pump | |
(W)power | 3000 | (MM)Steering cylinder diameter | φ50-25 | |
(ML/R)displacement | 14 | (pc)quantity | 2 | |
Walking system | ||||
(R/MIN)speed | 3000 | braking system | ||
Motor model | KC2500-60-QS | project | parameter | |
(V)Voltage | 60 | Service brakes | Drum brake | |
tire | (MM)Brake drum | 240 | ||
(W)power | 2500 | Parking brake | Drum brake | |
(R/MIN)speed | 3000 | (MM)Bucket oil cylinder diameter | φ73-35 | |
type | 23*8.5-12 | (MM)Lifting cylinder diameter | φ60-30 | |
working pressure | 0.3 | (pc)Number of lifting cylinders | 2 | |
quantity | 4 | |||
Oil capacity | ||||
project | parameter | |||
(L)Hydraulic oil tank | 38 | |||
(L)Brake fluid | 0.8 |
1.Environmental - friendly and Energy - saving
Zero emissions: Powered by electricity, electric loaders produce no exhaust emissions during operation, causing no pollution to the environment. They are especially suitable for use in enclosed or semi - enclosed places with high air - quality requirements, such as indoor areas, warehouses, and workshops.
Low noise: The motors of electric loaders generate relatively low noise during operation. Compared with traditional fuel - powered loaders, they can effectively reduce noise pollution in the workplace, improve the working environment, and minimize noise interference to operators and those around.
Low energy consumption: Electric energy has a relatively high conversion efficiency. Moreover, electric loaders usually adopt energy - saving technologies in their design, which can effectively reduce energy consumption and lower the operating costs.
2.Compact and Flexible
Compact size: The overall volume of the 400KG electric loader is relatively small. Its body length, width, and height are more compact compared to traditional loaders. It can freely move through narrow spaces, such as the passages in small warehouses, aisles in workshops, and some construction sites with limited space. It has flexible operation and a small turning radius, enabling it to easily perform actions like turning and U - turning.
Appropriate load capacity: Although its rated load is 400KG, this load capacity is sufficient for the handling and loading/unloading operations of some small - sized goods, meeting daily work requirements. Meanwhile, it won't be difficult to operate in small - scale sites due to excessive load.
3. Easy to Operate
Easy to learn: The control system of electric loaders is relatively simple. They usually adopt electro - hydraulic or electronic control technologies. The operation handles and buttons are reasonably arranged, conforming to ergonomic design. Operators can quickly get the hang of the operation skills after simple training.
4. Low Maintenance Cost
Simple structure: The power system and transmission system of electric loaders are simpler compared to traditional fuel - powered loaders. There are no complex components such as engines, transmissions, and drive shafts, which reduces the probability of mechanical failures and lowers the maintenance cost and difficulty.
Long maintenance cycle: The key components such as motors and batteries have a relatively long service life. They don't require frequent replacement of vulnerable parts like engines, such as engine oil and filters. The relatively long maintenance cycle can effectively reduce the equipment downtime and improve work efficiency.
5. High Safety
Good braking performance: Electric loaders are usually equipped with well - performing braking systems, including various braking methods such as electromagnetic braking and hydraulic braking. They can achieve braking and stopping in a short time, ensuring the safety of operators and equipment.
